AES | Cellcom Prime EDGE 4G Cellular Intercom | 1 Button | Modular Pedestal with Keypad and Prox Reader
The AES Cellcom Prime EDGE (part PRIME-EDGE-FBK-US) is a single-button 4G cellular gate intercom that calls up to four phone numbers in sequence, with a keypad and 125 kHz proximity reader. This version has a powder-coated black modular pedestal panel for flush mount. No phone line or cable trench is needed.
Key features
- Calls up to 4 phone numbers in sequence on one button press
- Keypad and 125 kHz proximity reader as standard
- 250 permanent and 250 time-restricted codes or prox cards
- 2 relay outputs, triggered, latched or unlatched over SMS
- Remote SMS diagnostics and firmware updates
- Managed in the AES PRO and AES HOME apps
Cellcom Prime EDGE Modular Pedestal: answer the gate from your phone
The Prime EDGE dials your phone in sequence when a visitor presses the call button, so a gate can be answered from the house, the office or the road. It runs on a 4G SIM on US and Canadian networks, which means no phone line and no cable trench between the gate and the building.
Keypad, prox and access codes
An illuminated keypad and backlit call button light up at night for clear visibility. Every US panel ships with the 125 kHz proximity reader as standard. The panel holds 250 permanent and 250 time-restricted codes or prox cards, 50 temporary codes and 250 caller ID numbers, with keypad lockout on by default and an optional two-factor entry.
Relays and power
Two relay outputs, normally open and normally closed and rated 2 A at 24 V AC maximum, can be triggered, latched or unlatched over SMS. The panel runs on 24 V DC from the 2 A adaptor in the box, drawing 300 mA on a call and 2 A at peak, and has third generation surge protection.
Apps and remote management
The AES PRO app stores sites and intercoms in the cloud, so an installer can log in from any phone, share a site and troubleshoot without driving back out. Homeowners use the simpler AES HOME app. SMS diagnostics, firmware updates over SMS, Do Not Disturb times and an events log are all built in. Ordered under AES part number PRIME-EDGE-FBK-US, with a 2 year manufacturer warranty.
Specifications
| Brand | AES Global |
| Power | 24 V DC, 2 A adaptor included |
| Fixing method | Flush mount |
| Warranty | 2 years, manufacturer |
| Product line | Cellcom Prime EDGE |
| Power consumption | 300 mA on call, 2 A peak |
| Relays | 2 (N/O and N/C, 2 A at 24 V AC max) |
| Details | |
|---|---|
| Panel | Powder-coated black modular pedestal panel |
| Keypad codes | 250 permanent, 250 time-restricted, 50 temporary |
| Proximity reader | 125 kHz |
| Call buttons | 1 |
| Dial-out numbers | 4 |
| Caller ID numbers | 250 |
| App | AES PRO (installer) and AES HOME (end user) |
| Network | 4G LTE, US and Canada |
What's in the box
- Callbox panel in the selected finish
- 4G cellular motherboard with modem
- 24 V 2 A power supply with US plug
- Security key set
Frequently asked questions
Does the Prime EDGE need a phone line?
No. It runs on a 4G SIM on US and Canadian LTE networks, so no phone line or cable trench to the building is needed.
How many phone numbers does it call?
Up to four, in sequence, when a visitor presses the call button.
What power does it need?
24 V DC. A 24 V 2 A power supply with US plug is in the box. It draws 300 mA on a call and 2 A at peak.
How many codes and cards can it hold?
250 permanent and 250 time-restricted keypad codes or prox cards, plus 50 temporary codes and 250 caller ID numbers.
