Ornamental Steel Fence Panel | Commercial | Flat Top
Commercial grade flat top ornamental steel fence panel with 1-1/2" rails and 3/4" pickets, 34" to 70" tall. Welded, black and sold per panel.
Key features
- Commercial grade: 1-1/2" square rails with 3/4" square pickets
- Flat Top: pickets finish flush with the top rail, for a clean, level line
- Welded 2-rail construction
- Black finish
- Mounts with 1-1/2" rail brackets, sold separately
- Sold per panel
Commercial grade flat top ornamental fence
A welded 2-rail panel with 1-1/2" square rails and 3/4" square pickets, the commercial profile in this range. It gives the look of wrought iron with the straight, even lines of welded square tubing, finished in black.
The flat top profile
On this panel the pickets finish flush with the top rail, for a clean, level line.
Sizes
- 34" high x 90" wide (3 ft fence): 19 pickets at 4-1/2" on center
- 40" high x 90" wide (3.5 ft fence): 19 pickets at 4-1/2" on center
- 45" high x 90" wide (4 ft fence): 19 pickets at 4-1/2" on center
- 58" high x 94" wide (5 ft fence): 19 pickets at 4-3/4" on center
- 70" high x 94" wide (6 ft fence): 19 pickets at 4-3/4" on center
Building a complete fence line
Each section mounts between posts with rail brackets sized for a 1-1/2" rail. In-ground posts in 2-1/2" and 3" square, surface mount posts with a welded base plate for concrete and slabs, and matching swing and sliding gates are in the same range, so a run comes from one line and one finish.
Specifications
| Brand | Fenceweb |
| Material | Steel |
| Finish | Black |
| Width | 7'6" (90") |
| Height | 3' (34") |
| Product line | Commercial |
| Sold as | Single panel |
| Details | |
|---|---|
| Top style | Flat Top |
| Rail size | 1-1/2" |
| Picket size | 3/4" |
Article numbers
- FW-2602003Height: 3' (34")$80.50Chosen
- FW-2602007Height: 6' (70")$142.00
- FW-2602006Height: 5' (58")$123.00
- FW-2602004Height: 3.5' (40")$89.00
- FW-2602005Height: 4' (45")$98.00
Frequently asked questions
Which rail brackets fit this panel?
The rails are 1-1/2" square, so use the rail bracket in size 1-1/2". One bracket holds one rail end; a panel between two posts takes four.
How wide is one section?
The 34" panel is 90" wide. The 40" panel is 90" wide. The 45" panel is 90" wide. The 58" panel is 94" wide. The 70" panel is 94" wide.
What is the difference between residential, commercial and industrial grade?
The grade is the tube size. Residential panels use 1" rails and 5/8" pickets, commercial panels 1-1/2" rails and 3/4" pickets, and industrial panels 2" rails and 1" pickets. A heavier tube makes a stiffer panel for taller runs and for sites that take more abuse.
