Turnstar Titan | Half-Height Turnstile | Single, 3 Arm, Galvanized
Single 3 arm half-height Titan turnstile in galvanized steel for staff and visitor entrances at factories, mines, warehouses and campuses.
Key features
- Single turnstile with a 3 arm rotor at 120 degree spacing
- Walkthrough width 1'8", overall height 4'
- Hot-dip galvanized mild steel
- Fail-secure as standard, fail-safe configurable per direction
- Mechanical key override in both directions
- Runs on 220 V AC, 110 V AC on request
- 10 year mechanical and 1 year electrical guarantee
Galvanized half-height turnstile with three arms
The Titan half-height turnstile controls one person at a time while keeping sight lines open, which suits factory gates, mine shafts, warehouses, universities and stadiums. It handles high traffic volumes at a medium security level and is built for both indoor and outdoor use in severe conditions.
A Rotalok electromechanical locking unit with a suspended rotor turns the 3 arm rotor bi-directionally and returns it to its start position after each passage. A dry contact from any access control or time and attendance system releases each direction, and the Anti-Trap system stops the rotor locking mid-turn when power fails. The frame bolts together in modules that pass through a standard door.
Options
- Turnstile screen in a matching finish
- Card, proximity or biometric reader mounting brackets
- Single or double pushbutton
- Red cross and green arrow LED indicator
- Coin acceptor for pay-for-entry use
- LCD transaction counter with reset key switch
- Random search device
- Battery backup with two 12 V 7 Ah batteries
Specifications
| Brand | Fenceweb |
| Manufacturer | Turnstar |
| Material | Mild steel |
| Finish | Hot-dip galvanized |
| Width | 4' (47-1/4") |
| Height | 2'8" (31-1/2") |
| Length | 8'2" (98-3/8") |
| Power | 220 V AC, 50/60 Hz (110 V AC on request) |
| Lock type | Rotalok electromechanical, fail-secure standard, fail-safe optional |
| Weight | 243 lb |
| Warranty | 10 years mechanical, 1 year electrical |
| Product line | Titan |
| Type | Half-height industrial turnstile, single, 3 arm |
| Power consumption | 50 W |
| Color | Galvanized |
| Details | |
|---|---|
| Integration | Normally open dry contact per direction, rotation complete output |
| Dimensions | 52-1/2" wide x 55-1/8" long x 47" high; Diameter: Rotor 47-1/4" |
Frequently asked questions
How do I get a price for a Turnstar product?
Every Turnstar product is built to order and quoted per project. Send us the model, the configuration, the finish, how many units you need and the delivery address, and we come back with a quote that includes freight to your site.
Who installs it?
It is galvanized.
Where are Turnstar products made?
Turnstar designs and builds its turnstiles, gates and barriers in its own factory in Johannesburg, South Africa, where it has made access control equipment since 1990. Its quality management is certified to ISO 9001:2015.
