Locinox | Hydraulic damper for TURNITEC for 3-arm turnstile (120°)
Locinox hydraulic damper for the TURNITEC mechanism on a 3-arm turnstile with 120 degree steps. The first half of each rotation is undamped and the second half is damped progressively, so the turnstile moves smoothly and does not hit the user's heels.
Key features
- For TURNITEC 3-arm turnstiles (120 degrees)
- Patented hydraulic damping
- Undamped first half, progressive damping in the second half
- Damping starts from 60 degrees of rotation
- Unaffected by temperature changes
- Easy to retrofit, tested for 1 million movements
Locinox TURNITEC hydraulic damper for 3-arm turnstiles
A turnstile that swings round freely can catch the heels of the person walking through. This hydraulic damper for the Locinox TURNITEC mechanism prevents that by slowing the arms in a controlled way, giving a fluent, gradual movement on every passage.
Operation
The first half of each rotation is undamped, and the second half is damped progressively by the continuous damping of the mechanism. In the 3-arm version, damping of the rotational movement starts from 60 degrees. The patented hydraulic system is unaffected by temperature changes, so the movement stays consistent through the seasons.
Compatibility and installation
The damper is made for TURNITEC turnstiles with three arms and 120 degree steps. It is easy to retrofit on an existing TURNITEC system, so an installed turnstile can be upgraded without replacing the mechanism.
Durability
Locinox has tested the damper for 1 million movements, which makes it suitable for busy pedestrian entrances where the turnstile is used all day.
Specifications
| Brand | Locinox |
| Weight | 8.7 lb |
| EAN | 5414768014455 |
Frequently asked questions
Can I add the damper to an existing TURNITEC turnstile?
Yes. It is easy to retrofit on an existing TURNITEC system.
When does the damping start?
In the 3-arm version, damping starts from 60 degrees and increases progressively over the second half of the rotation.
Does cold or hot weather affect it?
No. The system is unaffected by temperature changes.
