Shut It® 4" (102mm) Hardcore™ Cantilever Wheel
The Shut It Hardcore 4" Cantilever Wheel from D&D Technologies carries a sliding gate on a rail instead of a V-track on the ground. Super-hard cold rolled steel, adjustable plates and a 1,499 lb maximum gate weight make it suited to commercial and security gates.
Key features
- Cantilever wheel assembly that runs on a rail
- No ground track needed
- Super-hard cold rolled steel, 30RC rating
- Two sealed bearings, zinc finished steel plates
- Adjustable plates for precise installation
- Load rating 1,360 kg per gate, maximum gate weight 680 kg
Shut It 4" Hardcore Cantilever Wheel: for gates without a ground track
A cantilever wheel assembly is installed on a rail rather than on a V-track, which makes it the right choice where installing a track on the ground is not feasible. This assembly belongs to D&D Technologies' Shut It Hardcore range of sliding gate hardware.
Materials and finish
The wheel is made from super-hard cold rolled steel with a 30RC rating and runs on two sealed bearings. The carriage plates are steel with a zinc finish. Its narrow width reduces friction and problems with debris.
Sizes and fit
D&D rates the assembly at a load of 1,360 kg per gate and a maximum gate weight of 680 kg. It is specified for privacy, security and commercial gates.
Installation
The assembly is welded in place. Adjustable plates let you set the gate precisely during installation. It is sold individually as part CI2240 and carries D&D Technologies' limited lifetime warranty.
Specifications
| Brand | D&D Technologies |
| Manufacturer | D&D Technologies |
| Finish | Zinc |
| Fixing method | Weld-On |
| Weight | 5.0 lb |
| Warranty | Limited lifetime |
| Product line | Shut It HardCore |
| Type | Gate wheels |
| Function | Square-to-Square |
| Suitable for | Privacy Gate, Public/Commercial Gate, Security Gate |
| Max gate weight | 1500 lb |
| Sealed bearings | 2 |
| Max gate load | 3000 lb |
| Wheel material | Steel |
| Carriage plate material | Steel |
| Sold as | Each |
Frequently asked questions
When should I use a cantilever wheel?
When installing a track on the ground is not feasible. The wheel assembly runs on a rail instead of a V-track.
How heavy a gate can it carry?
D&D gives a maximum gate weight of 680 kg and a load rating of 1,360 kg per gate.
How is it fitted?
The assembly is welded in place, and its plates are adjustable.
