Turnstar Titan | Full-Height Turnstile | Double, 3 Arm, Galvanized
Galvanized double turnstile with three arms, for controlling pedestrian access at a site entrance. A turnstile lets people through one at a time; contact us for dimensions, height, flow rate and access control options before ordering.
Key features
- Double turnstile, two 3-arm rotors (120 degrees per passage)
- Overall size 84-5/8" wide x 83-5/8" high
- Recommended minimum opening 85-7/8" wide x 88-5/8" high
- Hot-dip galvanized mild steel finish
- Fail-secure as standard, fail-safe on request
- Mechanical key override in both directions
- Standby power use of 0.5 W in fail-secure mode
- 10 years mechanical and 1 year electrical guarantee
Galvanized double turnstile with three arms
The double Titan places two three-arm rotors side by side under one top beam, giving two controlled lanes where one frame would otherwise fit only one. It suits shift changes and other peaks at mines, factories, warehouses, colleges, building sites and stadiums. Each lane passes one person per authorised rotation, and the unit can stand indoors or outdoors.
Each rotor has its own Rotalok electromechanical lock with Anti-Trap protection against locking mid-turn during a power cut. The frame bolts together in modules that fit through a standard door, with built-in wireways and draw wires so no cables are exposed. Unlocking for entry and exit is triggered by a normally open dry contact from any access control or time and attendance system.
Options
- Battery backup with two 12 V 7 Ah batteries
- Solar panel with charge controller and batteries
- Flat roof canopy with anti-climb protection and light
- Fail-safe or fail-secure setting per direction
- Free rotation on a fire alarm signal
- Card, proximity or biometric reader mounting brackets
- LCD transaction counter with reset key switch
- Random search device
Specifications
| Brand | Fenceweb |
| Manufacturer | Turnstar |
| Material | Mild steel frame with 1-15/16" diameter tube arms spaced 4-3/4" apart |
| Width | 4' (47-1/4") |
| Height | 2'8" (31-1/2") |
| Length | 8'2" (98-3/8") |
| Power | 220 V AC (110 V AC on request), 50/60 Hz; 24 V DC solenoids and logic |
| Lock type | Rotalok electromechanical rotation lock, fail-secure as standard |
| Weight | 705 lb |
| Warranty | 10 years mechanical, 1 year electrical |
| Product line | Titan |
| Type | Full-height industrial turnstile, double, 3 arm |
| Power consumption | 0.5 W standby in fail-secure mode, 100 W in fail-safe mode |
| Color | Galvanized |
| Details | |
|---|---|
| Integration | Normally open dry contact for entry and exit, rotation complete output |
| Dimensions | 84-5/8" wide x 83-5/8" high; recommended opening 85-7/8" x 88-5/8"; Diameter: Rotor 47-1/4" |
Frequently asked questions
How do I get a price for a Turnstar product?
It is galvanized.
Who installs it?
Fenceweb supplies the equipment and delivers it to your site. Your own contractor or security integrator installs and commissions it, following Turnstar's installation instructions.
Where are Turnstar products made?
Turnstar designs and builds its turnstiles, gates and barriers in its own factory in Johannesburg, South Africa, where it has made access control equipment since 1990. Its quality management is certified to ISO 9001:2015.
What types of fencing products does Fenceweb offer?
Fenceweb offers a complete range of fencing products, including welded wire fence panels, chain link fence, ornamental and metal fencing, security fencing, fence posts, swing and farm gates, gate hardware and temporary fencing. We also carry trusted brands such as Locinox, Gatemaster, ZND, AES Global, D&D Technology and Tarter.
Are all products in stock and ready for shipment?
The majority of our catalog is kept in stock and ships quickly from our warehouse. We do not publish a stock figure on the product pages, so ask our team and they will confirm availability and lead times for your order, especially a larger or custom one.
Does Fenceweb provide installation services or recommendations?
Fenceweb supplies products rather than installation, but our specialists are happy to recommend the right materials for your project and can connect you with experienced fencing contractors in our partner network.
Still have questions? Call us at 214 878 1900
