Locinox Gate closers
Locinox is the Belgian specialist in gate and fence hardware: mechanical and hydraulic locks, hinges, gate closers, keeps, handles and code locks. The hardware is designed for swing and sliding gates in aluminum, steel and stainless steel, with a focus on durability and weather resistance.

Chain link bracket | Mammoth180-2
$97.58

Chain link bracket | Tiger
$78.07

Spring hinge | Serval | 180° with self-drilling screws
from $52.43

Cover | Rhino and Verticlose-2 | Uncoated aluminum
$40.34

Locinox

Adapter plate | Lion | for round posts
$20.00

Shell | Lion | Uncoated aluminum
$40.34

Rail clamp | Rail-Fit | for gate closers on barred fencing
$81.72

Chain link bracket | Caracal
$30.29

Adapter plate | Venus | for wall or 2-3/8" post
from $78.79

Drilling jig | Tiger
Contact us for pricing

Drill and assembly jig | Rhino
$74.24

Drill and assembly jig | Lion and Verticlose-2
$108.46

Ground fixation set | Interio
$141.20

Wall fixation set | Interio
$100.84

Gate closer | Rhino | 180° with direct connection to the hinge
from $689.15

Gate closer | Panther | All-round hydraulic, for wall and post mounting
$492.18

Motorized hinge and gate closer | Magnus | for pedestrian gates
Contact us for pricing

Sliding arm | Venus
from $78.79

Rail | Venus | for gates with 180° hinges
from $69.95

Articulated arm | Venus | for large hinge offsets
from $227.04

Mounting arm | Venus | for 180° hinges
from $227.04

Gate closer | Venus | Motorised, for pedestrian swing gates
from $1,476.10

Gate closer | Lion | Compact hydraulic, for every gate situation
from $446.93

Gate closer and hinge | Tiger | Compact hydraulic 180°
from $399.88
Highlights

Steady in any weather
Oil damping keeps the closing speed even.

New or retrofit
Closers for new gates and gates that already hang.

Many gate sizes
From compact pedestrian closers to large gates.

Hinge and closer in one
TIGER carries the gate and closes it in one part.
How does a hydraulic gate closer work?
Locinox gate closers work on a mechanical spring with oil damping. The spring provides the force that closes the gate; the oil controls the speed, so the gate does not slam. Hydraulic closers also hold the gate shut against wind load, and several models combine the closer with a hinge, so you need fewer parts on the hinge side.
Choosing by gate weight and width
The choice comes down to three numbers: gate weight, gate width and the opening angle you need. A wide gate needs more force than a heavy narrow one. Each product page lists the maximum gate weight and width the closer is made for; Tiger, for example, handles pedestrian gates up to 165 lb. Stay inside both limits: a closer that is too light for the gate wears quickly and may not close it fully.
- Weigh the gate or work out its weight from the frame and infill.
- Measure the gate width from the hinge side to the latch side.
- Decide whether the gate opens 90 or 180 degrees.
- Check where the closer can be fixed: post, wall or ground.
- Pick the closer whose limits cover all of these.
Closers combined with the hinge
These closers are combined with a hinge or connect directly to it, so the closing action sits on the hinge line.
- Tiger: compact hydraulic 180 degree closer and hinge
- Caracal: hydraulic 180 degree closer and hinge
- Rhino: 180 degree closer with a direct connection to the hinge
- Serval: 180 degree spring hinge, fixed with self-drilling screws
All-round closers for post and wall
- Lion: compact hydraulic closer for every gate situation
- Panther: all-round hydraulic closer for wall and post mounting
- Verticlose-2: all-round hydraulic closer for 90 and 180 degree hinges
- Verticlose-2-Wall: all-round hydraulic closer for wall mounting
- Samson-2: hydraulic closer for large gates
New fit or retrofit?
New fit closers are mounted while the gate is being built and become part of the hinge line. Retrofit closers bolt onto a gate that already hangs, without removing the existing hinges; Samson-2 and Verticlose-2-Wall are the usual choices there.
Invisible and built-in closers
Interio is an invisible, built-in hydraulic gate closer. It is built in, so the closer does not show on the gate. Order the Interio ground fixation set or wall fixation set for the way it is fixed at your gate.
Motorized Magnus
Magnus is a motorized hinge and gate closer for pedestrian gates. It automates a pedestrian gate with a motorized hinge that is also the gate closer. Ask us to check the power supply and controls it needs before you order.
Brackets, arms and adaptor plates
The parts that make a closer fit the gate you actually have are listed with the closers:
- Chain link brackets for Tiger, Caracal and Mammoth180-2, to mount the closer on a round chain link post
- Lion adaptor plate for round posts
- Venus parts: sliding arm, rail for gates with 180 degree hinges, articulated arm for large hinge offsets, mounting arm for 180 degree hinges and an adaptor plate for a wall or a 2-3/8" post
- Lion shell and Rhino and Verticlose-2 cover in uncoated aluminum
The Rail-Fit rail clamp, for closers on barred fencing, has its own page under Gate closer accessories.
Drilling jigs
A closer only works smoothly when its fixing holes sit in the right place. Locinox makes jigs for that: the Tiger drilling jig, the Rhino drill and assembly jig and the drill and assembly jig for Lion and Verticlose-2. They make the drilling repeatable from gate to gate.
Fitting a closer step by step
- Hang the gate on its hinges and check that it swings freely.
- Mark the fixing points with the jig or the template of the closer.
- Fit the closer and any bracket or adaptor plate it needs.
- Adjust the closing speed so the gate closes fully without slamming.
- Test the gate several times and check that the lock catches each time.
Ordering and delivery
Send us the gate weight, width, opening angle and post type, and we help you choose the closer and its fixing parts. Where a closer comes in more than one color, such as black (RAL 9005) or silver, choose the color on its product page. Fenceweb delivers to every US state and to Canada.
Frequently asked questions
Which gates is Locinox hardware suitable for?
Swing and sliding gates in aluminum, steel and stainless steel. The profile size and type determine the right lock, hinge or closer; dimensions are listed on every product page.
Are Locinox locks available in RAL colors?
Many items come in standard RAL colors such as RAL 9005 (black) and in silver or galvanized. The available color is stated per product.
Does Fenceweb deliver Locinox from stock?
The core Locinox range is in stock and ships quickly. Each product page shows the packaging unit and the delivery time.
What types of fencing products does Fenceweb offer?
Fenceweb offers a complete range of fencing products, including welded wire fence panels, chain link fence, ornamental and metal fencing, security fencing, fence posts, swing and farm gates, gate hardware and temporary fencing. We also carry trusted brands such as Locinox, Gatemaster, ZND, AES Global, D&D Technology and Tarter.
Are all products in stock and ready for shipment?
The majority of our catalog is kept in stock and ships quickly from our warehouse. We do not publish a stock figure on the product pages, so ask our team and they will confirm availability and lead times for your order, especially a larger or custom one.
Does Fenceweb provide installation services or recommendations?
Fenceweb supplies products rather than installation, but our specialists are happy to recommend the right materials for your project and can connect you with experienced fencing contractors in our partner network.
Still have questions? Call us at 214 878 1900
