Shut It® 6" (152mm) Hardcore™ V-Groove Wheel with Carriage
Shut It 6" (6") Hardcore V-Groove Wheel with Carriage - Designed for a gate with a bottom rail.
Key features
- 6" V-groove wheel with adjustable carriage plates
- Super-hard cold rolled steel, 30RC rating
- Two sealed, maintenance-free bearings
- Only 1-1/8" wide to reduce friction and debris
- Load rating 2,270 kg per gate, maximum gate weight 1,000 kg
- Models for 1-1/2" and 2" bottom rails
Shut It 6" Hardcore V-Groove Wheel with Carriage: for the heaviest sliding gates
This assembly combines the Shut It Hardcore 6" V-groove wheel with adjustable steel carriage plates. It is designed for heavy sliding gates with a bottom rail running on a V-track, and mounts the wheel inside the rail without a wheel box.
Materials and operation
The wheel is made from super-hard cold rolled steel with a 30RC rating. Two sealed bearings need no greasing and no maintenance. At only 1-1/8" wide, it reduces friction and problems with debris on the track.
Sizes and fit
Choose the model for your bottom rail width: 38 mm or 51 mm. D&D rates the assembly at a load of 2,270 kg per gate and a maximum gate weight of 1,000 kg, for privacy, security and commercial gates.
Installation
The carriage plates are welded in place and are adjustable, so you can set the gate precisely during installation.
Specifications
| Brand | D&D Technologies |
| Manufacturer | D&D Technologies |
| Fixing method | Weld-On |
| Weight | 12 lb |
| Warranty | Limited lifetime |
| Product line | Shut It HardCore |
| Type | Gate wheels |
| Function | Square-to-Square |
| Suitable for | Privacy Gate, Public/Commercial Gate, Security Gate |
| Max gate weight | 2200 lb |
| Sealed bearings | 2 |
| Max gate load | 5000 lb |
| Wheel material | Steel |
| Carriage plate material | Steel |
| Sold as | Each |
| Gate frame | 1-1/2" |
Article numbers
- CI2715Gate frame: 1-1/2"$107.00Chosen
- CI2720Gate frame: 2"$107.00
Frequently asked questions
How heavy a gate can it carry?
The Shut It 6" (6") Hardcore V-Groove Wheel with Carriage is rated for gates up to 2200 lb. Staying inside that rating is what keeps the closing action reliable over the life of the gate.
Which model do I need?
Choose by the width of your gate's bottom rail: 1-1/2" or 2".
Are the plates adjustable?
Yes. The carriage plates adjust so the gate can be set precisely, and they are welded in place.
