Gatemaster | Sliding Gate Lock | RapidReset | Double-Sided Keypad
Designed for gates that require controlled entry and exit, the double-sided Superlock Sliding Gate Lock features mechanical keypads with RapidReset on both faces, allowing full control from either side of the gate without the need for power or wiring. With a robust latch system and smooth lever handles, it’s the ideal solution for securing sliding gates in high-traffic or restricted-access environments.
Key features
- Change the code in just 10 seconds with RapidReset
Certain features of this product are protected under European Patent No. 3354825. Any unauthorised reproduction, use and/or sale of this product may constitute an infringement of our patent rights.
Watch the video
Specifications
| Brand | Gatemaster |
| Manufacturer | Gatemaster |
| Patent | EP 3354825 |
| Warranty | 5 years |
What's in the box
- 0.098" hex key + 0.118" hex key
- M8 fixing bolts
- Face plate
- Adjustable keep with self-expanding fasteners
Installation
- 1Drill two 3/8" holes at 5-1/2" centers through the front stile of the gate for the fixing bolts (provided)
- 2Drill a 1" hole for the latch arms, centered between the two holes
- 3Slide the lock through the holes from the back of the box section, fit the formed stainless steel support plate and fix it with the 2 M8 countersunk screws supplied.
- 4Mark where the latch arms will strike the gate post and drill a 1" receiving hole
- 5Drill 2 x 15 mm holes at 70 mm centres above and below the receiving hole.
- 6Fit the L-shaped keep plate supplied by tightening the expanding fasteners. The keep should block access from the front (secure) side of the gate.
Related products
Frequently asked questions
Will it survive outdoors all year?
It is built for it. The bodies are pressure die-cast and powder-coated, latchbolts are stainless steel and the keypads are marine grade, so salt air and rain are not a problem. Follow the maintenance schedule on this page - a spray of light oil a few times a year is what keeps a gate lock feeling new after a decade outside.
What warranty comes with this product?
Gatemaster gives a 5-year warranty on the Superlock 2.0 range and a manufacturer's warranty on the rest of the program, covering defects in material and workmanship. Keep your invoice: that is the proof of purchase a claim is assessed on. Damage from forcing, from the wrong installation or from missed maintenance is not covered - which is why the maintenance schedule on this page is worth following.
Is this in stock and how fast can I get it?
Gatemaster hardware is part of our standard program, so the common versions ship from stock. If you need a quantity for a project, or you are not sure which version fits your gate, ask us for a quote - we will check the frame size and handing with you before anything is picked.
How fast can I change the code on a RapidReset model?
In about ten seconds, without taking the lock off the gate and without tools. That matters where the code has to change often - a building site, a holiday let, a shared bin store or after a contractor leaves. The mechanism stays mechanical, so there is still nothing to power or charge.
Does this code lock need power or batteries?
No. The keypad is fully mechanical, so there is no wiring, no batteries and nothing to replace. That is what makes it suitable for gates at the far end of a site, allotments, bin stores and anywhere a cable run would be impractical - and it keeps working in a power cut.
