Gate Drop Bolt

A drop bolt holds the passive leaf of a double gate in place by dropping a steel bolt into the ground or into a ground catcher. Without it, the second leaf would swing free and the lock on the active leaf would have nothing to close against. Choose a manual, lockable or auto-locking drop bolt, or an electric bolt when the gate is part of an access control system. Read more

Highlights

For double gates

For double gates

Pins the passive leaf, so the active leaf has something to lock to.

Lockable Keydrop

Lockable Keydrop

The Locinox Keydrop locks the bolt down with a key.

Ground catcher

Ground catcher

A catcher in the paving keeps the hole clean and the bolt in line.

Electric gate bolt

Electric gate bolt

The AES Tomalok throws 5.9", for gates on access control.

Why a double gate needs a drop bolt

A double gate has two leaves that meet in the middle. One leaf, the passive leaf, is pinned in place by a drop bolt; the other, the active leaf, latches or locks to it. The Fortress Versai Pro Series drop rod works exactly like that: it pins the inactive leaf into the ground, so the active leaf has a fixed point to latch against.

Manual and lockable drop bolts

  • Locinox Keydrop: a lockable drop bolt.
  • Locinox Suby: an internal drop bolt.
  • Fortress Versai Pro Series drop rod: for Versai double and drive gates, in black to match the gates and hardware.
  • Gatemaster surface fixed locking drop bolt, in standard and stainless steel versions: it fits to the gate with expanding fasteners. Once the bolt is in the ground, the locking plate is rotated around the edge of the gate, and once the second leaf is closed the bolt cannot be lifted.

In Gate Latch you will also find the D&D LokkBolt, with a rekeyable lock, and the padlockable D&D Q-Bolt.

Auto-locking drop bolts

The Gatemaster auto-locking drop bolt comes in a version to bolt on, the ADBS, and a version to weld. Its lifting plate sits between the two gate leaves, so the bolt cannot be lifted unless the gate is unlocked.

Electric gate bolts

The AES Tomalok is an electric drop bolt with a 5.9" throw, stainless steel roller bearings and a key-operated release override. It comes in black powder coat or stainless steel, on its own or as a kit with a ground plate and a 24 V power supply, and it drives a 24 V DC beacon directly. Use it where the gate is opened by an access control system and the passive leaf has to lock and release with it.

What does the drop bolt go into?

A drop bolt needs a hole or a catcher in the ground. A ground catcher, such as the EGS economic ground catcher for drop bolts listed in Gate Hardware, keeps the hole clean and the bolt in line; the Tomalok kit comes with its own ground plate. In paving or concrete, a proper catcher stops the hole filling with grit.

Fitting a drop bolt

  1. Close both leaves and line them up in the middle.
  2. Fix the drop bolt to the passive leaf, by welding, bolting or expanding fasteners as the product needs, at the end where it meets the ground.
  3. Mark the position of the bolt on the ground and fit the catcher or ground plate there.
  4. Test that the bolt drops fully and that the active leaf latches against the passive leaf.

Ordering

Gate drop bolts are delivered to every US state and to Canada. A drop bolt shown without a price is sold on request.

Good to know

Frequently asked questions

Does a double gate need a drop bolt?

Yes. The passive leaf has to be pinned in place, usually by a drop bolt into the ground, so the active leaf has a fixed point to latch or lock against.

What is an auto-locking drop bolt?

A drop bolt whose lifting plate sits between the two gate leaves, such as the Gatemaster ADBS, so the bolt cannot be lifted while the gate is locked.

Can a drop bolt be locked?

Yes. The Locinox Keydrop is lockable, the Gatemaster surface fixed locking drop bolt cannot be lifted once the second leaf is closed, and the D&D Q-Bolt takes a padlock.

How does an electric gate bolt work?

The AES Tomalok throws its bolt 5.9" electrically on 24 V, the kit includes a 24 V power supply, and a key-operated override releases it by hand.

What does the drop bolt go into?

A hole or catcher in the ground, such as a ground catcher for drop bolts, or the ground plate supplied with the Tomalok kit.
